BDP-(Metallized Polypropylene Film) Used in fans, air-conditioners, refrigerators, Power Systems (UPS), office equipment,mercury lamps, fluorescent lamps and business machines.

REQUEST A QUOTE PREV NEXT

Introduction

The capacitor are non-inductively wound with a metallized polyester film dielectric/electrode encapsulated in flame retardant(UL 94V-0) plastic case(PBT) and epoxy resin and seal.

★Used in fans, air-conditioners, refrigerators, Power Systems (UPS), office equipment,mercury lamps, fluorescent lamps and business machines.

Leads Type

P：UL 1015 or UL1007 stranded PVC insulation wire.

Specification

•Base Specification：

(a)IEC60252-1:2001：Used for AC motor application

(b)JIS C 4908：Used for electrical apparatus

(c)CNS 4327：Used for electrical apparatus

•Climate Category：In accordance with IEC60068-2-3

(a)H=Minimum Limit Temperature：-25℃

(b)S=Maximum Limit Temperature：+85℃

(c)F=Humidity Category：Average relative humidity≦75﹪,

95﹪ for 30 days per year, continuously；

85﹪ for the remaining days,occasionally.

•Rated Voltage：

250, 300, 350, 400, 450 VAC

•Capacitance Range：

3μ F ~ 50 μF

•Capacitance Tolerance：

U(- 5%~ +10%), J ( ± 5 % ), K (± 10 % )

•Withstand Voltage：

(a)Between Terminals：R.V. ×√2× 175% for 1 minuite（VDC）.

(b)Between Terminals and Case：2× rated voltage ＋1,000V(1500V Min) for 60s.

This test occasional self-healing breakdown is allowed.

•Disssipation Factor：

0.1﹪at 200V.AC, 60Hz and 25℃

•Insulation Resistance：

(a)Between Terminals：Insulation resistance：more than 1,000 Mohm μF

(b)Between Terminals and Case：≧10 MΩ Measured at 100V.AC, 60s. And 25℃

Dimension

UNIT：（mm）

Round Type Specification （Dimensions OD×H in m/m）
R.W	250 ~ 300V.AC		350V.AC		400V.AC		450V.AC
size	OD	H	OD	H	OD	H	OD	H
Cap μF.	OD	H	OD	H	OD	H	OD	H
3	25	40	25	40	30	40	30	40
4	25	40	30	40	30	52	30	52
6	25	40	30	52	30	60	30	60
8	30	40	30	52	35	60	35	60
10	30	40	35	60	35	60	35	60
12	30	40	35	60	40	60	40	60
16	31	52	35	60	40	60	40	60
18	31	52	35	60	40	60	40	60
20	30	60	40	60	45	60	45	60
25	35	60	40	60	45	60	45	60
30	35	60	40	85	40	100	40	100
35	35	60	40	100	45	120	45	120
40	40	60	40	120	45	120	45	120
45	45	60	45	120	51	120	51	120
50	45	60	45	120	51	120	51	120

(We can design dimensions as the customer like)

SPECIFICATION

TYPICAL PART NUMBER					RANGE VOLTAGE		TOLERANCE CODE
BAE	106	K	2E	CL	2E	2F	U= ＋10－5
Type capacitance tolerance voltage terminal screw					250VAC	300VAC	J = +/- 5%
N - no mounting ear.					2P	2G	K= +/- 10%
					350VAC	400VAC	M= +/- 20%
					2S	2H
					450VAC	500VAC
