•Base Specification：
(a)IEC60252-1:2001：Used for AC motor application
(b)JIS C 4908：Used for electrical apparatuss
(c)CNS 4327：Used for electrical apparatus
•Climate Category：In accordance with IEC60068-2-3
(a)H=Minimum Limit Temperature：-25℃
(b)S=Maximum Limit Temperature：+70℃
(c)F=Humidity Category：Average relative humidity≦75﹪,
95﹪for 30 days per year, continuously；
85﹪for the remaining days, occasionally.
•Rated Voltage：
250, 300, 350, 400, 450 Vac
•Capacitance Range：
3μ F ~ 50 μF
•Capacitance Tolerance：
U(- 5%~ +10%), J ( ± 5 % ), K (± 10 % )
•Withstand Voltage：
(a)Between Terminals：R.V. ×√2× 175% for 1 minuite（VDC）.
(b)Between Terminals and Case：2× rated voltage ＋1000V(1500V Min) for 60s.
This test occasional self-healing breakdown is allowed.
•Disssipation Factor：
0.35﹪at 200V.AC, 60Hz and 25℃
1.0﹪at 200V.AC, 1KHz and 25℃
•Insulation Resistance：
(a)Between Terminals：Insulation resistance：more than 1,000 Mohm μF
(b)Between Terminals and Case：≧10 MΩ Measured at 100V.AC, 60s. And 25℃
