MDR-CDI Type Condenser Discharge Ignition

Reference data
  • Capacitance range: 0.1~2.2㎌
  • Capacitance Tolerance: ±10%
  • Rated voltage (DC): 400~450V (160Vac/200Vac)
  • Climate category (IEC 60068-1): 40/110/21 (reduce operating voltage when operating temperature is higher than +85℃)
  • Reference Specification: IEC 60384-2
  • Coating material: Comply with UL94V-0 standard
Featured Apps
  • Self-healing properties
  • Flame retardant epoxy resin (UL 94V-0)
  • Coating Type (Powder Encapsulation)
  • Available in loose boxes and loose polybags

PFC Input Capacitor for LCD/PDP Power Supply Suitable for absorbing power filter noise
